EJ101IA-01G is a 10.1-inch LCD module product with a-Si TFT-LCD technology, which is represented by Shenzhen Zhiyuan Optoelectronic Technology Co., Ltd. (Innolux). It is equipped with WLED backlight, no backlight drive and no touch. ILI6192+ILI5801 driver IC has been bonded. As an IPS, normally black display and transmissive liquid crystal module product, EJ101IA-01G can provide a display brightness of 550 CD/m, a transmission contrast of 1000:1, and a viewing angle of 85/85/85 (typ.) (Cr ≥ 10) (L/R/U/D), and the best viewing angle is full. Because each pixel adopts 6-bit+Hi-FRC gray scale signal, this product can display 16.7M color, and its color saturation has reached 50% (NTSC). For backlight, this product adopts 3S10P WLED side-entry light source, and the service life of the light source is 15K hours, excluding backlight drive. EJ101IA-01G adopts LVDS (1 ch, 8-bit) signal interface, with a total of 40 pins, connected by terminals, and the screen driving voltage is 2.5/8.2/12.5/-13v (typ.) (vdd/avdd/vgh/vgl). Its typical vertical refresh rate Fv is 60Hz. If you want to adopt EJ101IA-01G LCD module in developing new products, it is recommended that you ask Innolux or its agents for the latest production status information and technical information about EJ101IA-01G. Please refer to the specification for panel parameters! According to the information held by Screen Library, this product was mass-produced in Q3, 2012, and the current production status is in mass production. At present, EJ101IA-01G is the main model product in the market. EJ101IA-01G has a working temperature of-10 ~ 60 C and a storage temperature of-20 ~ 70 C.. Based on its high brightness, white LED backlight, flip-chip terminal and other characteristics, this model is recommended for tablet computers, industrial equipment, industrial control equipment, testers and other products. Division I is a regular agent of Qunchuang, which has been in stock for a long time. Customers in need can call for advice!
